Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	Max. 400 W
Protection class:	Protection class I
Power connection:	Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Power:	Rated: 300W RMS LF Rated: 50W RMS HF
Frequency range:	40 - 20000 Hz
Sensitivity:	96 dB
Max. SPL:	121 dB
DSP:	Digital signal processor FIR Filter
DSP presets:	MUSIC; DJ; MONITOR; SUB
Attachment system:	Dual flange: Ø 35mm (0° / 5°)
Circuitry:	Class D Biamp
Control elements:	Power switch, level control per channel, Input sensitivity switch, tone control
Controls:	Limiter
Status LED:	Power, signal, clip, DSP presets
Connections:	Output: line via 1 x 3-pin XLR
Input channels:	1 x mono with mic-line switch via Combination socket (XLR/jack), channel control via rotary dial 1 x mono via Combination socket (XLR/jack), channel control via rotary dial
Speaker:	1 x woofer 15" Voice coil compression tweeter highs 1.35"
Type of speaker:	Compact cabinet speaker
Type of construction:	Vented
Carrying handle:	2 pc/pcs
Material:	Plastic
Color:	Black
Dimensions:	Length: 41 cm Width: 43 cm Height: 70 cm
Weight:	21.35 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397699678	23,25 kg	48,5cm x 44cm x 75cm

Spare parts

tweeter 1,35" 8Ohm XIRA-215A

woofer 15" 4Ohm XIRA-215A

Pcb (Amplifier) XIRA-215A (complete)

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
11039019-Images-.zip

Publications

Move Magazine #2/2022 E

On page: 90

Size: 28 MB

OMNITRONIC XIRA-215A Active 2-Way Speaker FIR-DSP

Name: OMNITRONIC XIRA-215A Active 2-Way Speaker FIR-DSP
Brand: OMNITRONIC
SKU: 11039019
Price: 349.00 EUR
Availability: InStock

Active speaker with 15" woofer, 1.35" driver, 300 W RMS LF, 50 W RMS HF-MainBild

Active speaker with 15" woofer, 1.35" driver, 300 W RMS LF, 50 W RMS HF-Bild-1

OMNITRONIC XIRA-215A Active 2-Way Speaker FIR-DSP

Stock for approx. 12 wk(s)

349,00 €

Find a dealer

Stock for approx. 12 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 11039019

Active speaker with 15" woofer, 1.35" driver, 300 W RMS LF, 50 W RMS HF

Active PA speaker system for touring applications and permanent installations
DSP-controlled biamp amplifier (class D)
2-way bassreflex enclosure with 38 cm woofer and 3.5 cm titanium driver
Line input (XLR/6.3 mm jack) with separate level control
Mic/line input (XLR/6.3 mm jack) with separate level control
Mixed output for linking further active speaker systems
Digital signal processor FIR Filter
DSP presets: MUSIC; DJ; MONITOR; SUB
Dual flange
Black metal grille
2 Rugged carrying handles
Application possibility: Standing; monitoring; on stand
For application areas such as: Clubs/dancing school; mobile use; mobile djs / entertainer; rental

Technical specifications

Spare parts

User manual

Downloads

Manufacturer information

Scope of delivery

Accessories

Loading accessories. Please wait...

OMNITRONIC XIRA-215A

Powerful active speaker for DJ and live applications

Powerful performance

OMNITRONIC's XIRA active 2-way loudspeaker impresses with its high, distortion-free output. With 300 watts RMS power for the woofer and 50 watts RMS for the tweeter, XIRA makes the stomach quiver. At the same time, the sound remains distortion-free.

Clear sound with presets

The DSP-controlled Class-D biamp amplifier offers four convenient presets that ensure crystal-clear, consistently good sound for any application: "MUSIC" provides a slight bass and treble boost, "DJ" gives the sound more presence and bass, "MONITOR" is the right choice for use as a floor monitor, and "SUB" fits whenever an additional subwoofer is used.

Flexible use

The design of the low-vibration and robust housing is not only visually appealing, but also allows flexible use of the XIRA: The active box can be mounted on a tripod or set up as a floor monitor. For tripod mounting, the box features a double flange with 0° and 5° tilt.
